Who is Gates?
Gates Corporation is a company based in the USA and one of the world’s largest suppliers of belts and drive systems for automobiles, two-wheelers, transportation and materials handling. The Carbon Drive was developed by Gates specifically for use on bicycles and was launched in 2006 as the first product of its kind.
What is a Gates Belt Drive?
Gates belt drives are a type of bicycle transmission system that use a belt instead of a traditional chain to transfer power from the pedals to the rear wheel. Gates belt drives offer several advantages over traditional chain drives, including greater durability, reduced maintenance, and smoother and quieter operation.
There are two over-arching technologies of Gates belt drives for bikes: CenterTrack and Carbon Drive.
- CenterTrack Gates Belt Drive: This type of Gates belt drive features a center rib that helps to keep the belt in place and reduces the risk of the belt slipping off the CenterTrack sprockets. CenterTrack Gates belt drives are available in CDX, CDC and CDN versions, with CDX being the higher-end option designed for more demanding applications such as electric mountain biking or adventurous touring.
- Carbon Drive Gates Belt Drive: This type of Gates belt drive uses carbon fiber as the reinforcing material for the belt, which makes it lighter and more durable than chain drives. The carbon fibers are spun into a flexible cord like structure (carbon fiber tensile cords) which are able to withstand huge linear forces while maintaining a low stiffness and high flexibility.
Is a Gates Belt Drive better than a bicycle chain?
Here are some of the advantages of belt drive bikes:
- Quiet: Belt drive bikes are much quieter than chain drive bikes. This is because there is no metal chain to grind against the gears.
- Clean: Belt drive bikes are much cleaner than chain drive bikes. This is because there is no oil to drip on the frame or your clothes.
- Strong: The tensile strength of a Gates Carbon Belt Drive is up to 250 MPa (36,275 psi). This is significantly higher than the tensile strength of a typical chain, which is around 100 MPa (14,500 psi). The high tensile strength of a Gates Carbon Belt Drive is due to the use of carbon fiber tensile cords in the belt. These cords are very strong and can withstand a lot of stress.
- Durable: Belt drive bikes are very durable. The belt is made from a strong, lightweight material that is resistant to wear and tear. The carbon fiber tensile cords combined with Polyurethane and nylon make the belt very durable and resistant to wear and tear.
- Low-maintenance: Belt drive bikes require very little maintenance. There is no need to oil the belt or adjust the gears as frequently….if at all.
If you are looking for a low-maintenance, quiet, and durable bike, a belt drive bike is a great option.
How strong is a Gates Carbon Belt?
The tensile strength of a Gates Carbon Drive belt can vary depending on the specific model and size of the belt. However, as a general range, Gates Carbon Drive belts typically have a tensile strength of 1,250 – 1,500 Newtons (N) for the CDX version and 880 – 1,250 N for the CDN version.
It’s worth noting that Gates Carbon Drive belts are designed to withstand high tensile forces, which is why they are able to provide a reliable and durable means of transferring power from the pedals to the rear wheel on bicycles. The carbon fiber construction of the belt allows it to be strong, yet lightweight and flexible, which makes it an attractive alternative to traditional chain drives.
Are Gates Carbon Belts as efficient as a bike chain?
Closed, circumferential carbon fiber strands transmit drive power directly and without elastic stretch for maximum safety and efficiency.
Which eBikes are compatible with Gates Carbon Belt Drives?
All Gates belt drives are compatible with a variety of bikes, including single-speed, internally-geared, and rear derailleur-equipped bikes. When choosing a Gates belt drive, it’s important to make sure that the sprockets and belt are the correct size for your bike’s frame and gearing system. Additionally, it’s important to ensure that the belt tension is properly adjusted to prevent excessive wear and prolong the life of the belt and sprockets.
The high tensile strength of a Gates Carbon Belt Drive is one of the reasons why it is a popular choice for electric bikes. Electric bikes are often used for heavy-duty applications, such as commuting and delivery. The high tensile strength of a Gates Carbon Belt Drive can withstand the heavy loads and torque that are generated by electric motors.
